• 19+19 Crossed Laser Lines
  For High Efficiency Scanning, acquires high quality data from large objects quickly7 Parallel Laser Lines
  For Fine Details Scanning, captures lines and sharp edges on componentsSingle Line
  For Deep Holes Scanning, reaches deeper to capture fine details with 1:4 diameter- depth ratio

Save Scanning Preparation Time and Cost
For feature-rich surfaces, EinScan Trak scanner mode delivers a smooth, marker-free laser 3D scanning experience. (Note: For high-accuracy requirements, global markers are still recommended.)

Real-Time Adjustment During Scanning
Up to 4 meters scanning distance and 0.05 mm resolution. Support for Ultra-Fine Scanning, During scanning you can switch between different resolutions in one scan and customize areas that require more details in the local resolution function.

Less Redundant Data, Higher Efficiency
Supports data alignment between tracking mode and scanner mode, with compatibility across multiple resolution (point distance) and laser lines.

Ideal for Various Materials
Scan black and reflective surfaces effortlessly without any data loss.

Multi-Environment Adaptability
Reliable scanning outdoor & indoor, supports scanning under strong outdoor light up to 110,000 lux.

No Battery Anxiety
Up to 5.5 hours of battery life in tracker mode, with hot-swappable batteries for uninterrupted operation. Scanner mode supports up to 3.5 hours of use.

5-10 Minutes Calibration, Built for Changing Environments
Quickly calibrate the full system and maintain reliable performance from -10°C to 40°C, with fewer recalibrations and greater workflow efficiency.

Safe to Transport, Easy to Carry
High-strength CFFIM carbon fiber, built for shock resistance and worry-free transport.

Equipped with a 5MP high-definition camera that can restore high-quality texture details,  allowing designers, engineers, and artists to maintain a high fidelity of the model during the digitization process, providing more precise information for subsequent analysis and creation.

• Wireless scanning: Without connecting to PC
• Wireless transfer: Data sharing to SHINING 3D Cloud
• Wireless screen casting: Display on a second screen
